Display : 15.6 inch Resolution : 1920*1080 IPS
RAM : DDR3 2GB Flash : 16GB
OS : Google Android 5.1/6.0/8.1 WiFi: 802.11 b/g/n
Bluetooth : Yes HDMI: Yes RJ45: YES
Camera : Front: 2.0 MP camera VESA: 100x100mm
Speaker: 2*2W Adaptor: 12V,3A
Note: Without battery, include Power Adapter
Product Description
15.6 Inch RK3288 BT4.0 POE Digital SignageFull HD 15.6 Inch RK3288 BT4.0 POE Digital Signage
15.6'' RK3288 Wall Mounted Touch Screen PoE Android8.1 Digital Signage advertising displyer
Product Product features:
OS: Android 8.1 / 15.6 Android digital signage All in one tablet
Various input-output ports: DC in, HDMI output, mini USB OTG,USB 2.0 host, 3.5mm audio jack, RJ45(PoE), SD card slot
Connection: supports Wi-Fi, Bluetooth 4.0, RJ45, PoE optional Digital Signage
Built for 24/7 use: strong durability supported to present business messaging 24/7
Full HD image: class-A LCD panel, HD image
Detail Specification
| System | CPU | RK3288 Quad core cortex A17 |
| RAM | 2GB | |
| Internal memory | 16GB | |
| Operation System | Android 5.1/6.0/8.1/9.0 | |
| Touch Screen | 10-Point capacitive touch | |
| Display | Panel | 15"LCD panel |
| Resolution | 1024*768 | |
| Viewing angle | 80*80*80*80 | |
| Display mode | Normally black | |
| Contrast ratio | 800 | |
| Luminance | 250 cd/m2 | |
| Aspect Ratio | ,4:3 | |
| Network | WiFi | 802.11b/g/n |
| Ethernet | 10M/100M Eethernet | |
| Bluetooth | Bluetooth 4.0 | |
| Interface | Card slot | SD,support up to 32GB |
| Mini USB | USB OTG | |
| USB | USB Host 2.0*3 | |
| Power Jack | DC power input | |
| RJ45 | Ethernet | |
| HDMI | HDMI output | |
| Earphone | 3.5mm earphone | |
| Media plays | Video format | MPEG-1,MPEG-2,MPEG-4,H.265,H.264,VC-1,VP8, etc.,support up to 4K |
| Audio format | MP3/WMA/AAC etc. | |
| Photo | jpeg |
Use Scenarios
15.6 inch digital signage1. Supermarket advertising: It can be used for shops to display their own product details, prices and other information, as well as advertising in the elevator, and so on
2. Medical treatment: It can be used for doctor information display screen at the entrance of the clinic, doctor information display in the corridor, and registration display screen
3. Gym: treadmill exercise, heart rate, speed and other information display, exercise information record display, rowing machine display, strength, speed, boxing, yoga and other tutorial video play
4. Catering industry: It can be used for a variety of small, medium and large milk tea shop product information display, catering advertising, food production process video play, corporate chain example display
Detail Image
